Avionics Systems
Garmin G5000 Display Unit (PMA Alternate)
PMA-approved replacement display unit compatible with Garmin G5000 integrated flight deck. Used on Bombardier Challenger and Gulfstream G650.
Key Information
- Part Number: AVN-GAR-G5000-003
- Certification: FAA / EASA / CAAC
- Traceability: Full documentation included
Notice: Alternative solutions are supplied for industrial gas turbine and non-certified applications unless otherwise agreed in writing.
Product Details
PMA Certification Details
This display unit holds FAA Parts Manufacturer Approval (PMA) as a direct replacement for the Garmin G5000 integrated flight deck primary display. The PMA designation ensures full interchangeability with the original equipment while offering significant cost savings over OEM procurement.
Platform Compatibility
Approved for installation on Bombardier Challenger 300/350/650 series and Gulfstream G650/G650ER business aircraft. The unit interfaces directly with the existing G5000 avionics suite via ARINC 429 and Ethernet data buses, requiring no additional wiring or software modifications.
Display Specifications
The 14.1-inch high-resolution LCD panel delivers 1920x1200 pixel resolution with 16.7 million color capability. Sunlight readability exceeds 1000 cd/m2 brightness, and the capacitive touchscreen supports both gloved and ungloved operation in accordance with DO-160G Section 19.
Installation Guidance
Installation follows the standard G5000 tray form factor with identical mounting points and connector pinout. Typical installation time is under 2 hours for qualified avionics technicians. The unit automatically synchronizes configuration data from the G5000 system upon first power-up.
